ZEISS Axioscope 5FL - LED Fluorescence Microscope

Getting Multichannel Fluorescence Images with One Click

  • Digital Multichannel Fluorescence
  • Light Manager
  • Digital Objective Detection
  • Fast Image Acquisition on Microscope Tripod
  • 2 Megapixel CMOS Mono Camera
  • Multi-channel fluorescence images

Grouped product items
Product Name Qty
ZEISS Axioscope 5 with HXP 120 fluorescence combined with LED transmitted light, with objectives EC Plan-Neofluar 5x, 10x, 40x, 100x Oil , incl. 202 mono camera (4K)

ZAS5-0052

ZEISS Axioscope 5 LED fluorescence for RGB-UV combined with LED transmitted light, with objectives EC Plan-Neofluar 10x, 20x, 40x and with optional differential interference contrast, incl. 202 mono camera (4K)

ZAS5-0051

Product Details

Description

Your smart microscope for more efficient routine lab work

ZEISS Axiolab 5 FL-LED is ready for use without being dependent on a computer. In combination with the Axiocam 202 mono or Axiocam 208 color microscope cameras, you have all the advantages of an intelligent stand-alone microscope system: you can take images and videos directly on the tripod. Control the camera via the screen display using the mouse (and keyboard if necessary). Store all microscope and camera metadata, as well as scaling data.
The LED fluorescence is powerful, gentle on samples and extremely long-lasting. An adjustment of the fluorescent lamp is no longer necessary.



ZEISS ZEN for research applications

Use the ZEN Imaging Software from ZEISS to additionally process and analyse your images.







Specifications:

Tripod equipment and accessories

  • Nosepiece 6x Coded
  • Filter wheel 6-fold for filters with diameter 36 mm in DL
  • Control button for Eco Mode and Light Manager
  • Snapshot function supports ZEISS Axiocam
  • USB 2.0 interface
  • Eyepieces 10x/23 Br. Foc
  • Camera adapter 60N-C 2/3" 0.5x



Overview of the possible variations:

  Methods
Objectives
Condensor Illumination Camera Specials
ZAS05-0051

Brightfield/ Colibri 3-FL
optional HXP120-FL

N-Achroplan or EC Plan-Neofluar 10x, 20x, 40x, 63x 0,9/1,25 HF or achromatic-aplanatic 0,9 HF D Ph DI LED/(HAL 100) Axiocam 202
mono

LED Fluoreszenz RGB-UV, optional DIC, Reflektorrevolver 4 oder 6x codiert, diverse FL-Filters

ZAS05-0052

Brightfield/
HXP 120 Fluoreszenz

EC Plan-Neofluar 10x, 20x, 40x 100xOil

achromatic-aplanatic 0,9 B D Ph DIC LED Axiocam 202 mono





More models and configurations available. For more information and support please contact us!

>>> Sales only within Germany! <<<

More Information

More Information
Type
AxioScope 5
Application
LM
Fluorescence Microscopy
Manufacturer
ZEISS
