ZEISS Axioscope 5 - smart microscope for routine and introductory research

Getting multichannel fluorescence images with one click.

Digital Multichannel Fluorescence
Automated Light Manager
Automated Objective Detection
Image Capture Button on Microscope Body
4K-Camera with Ultra HD Resolution

Grouped product items
Product Name	Qty
ZEISS Axioscope 5 LED for transmitted light-brightfield with objectives A-Plan 5x,10x, 40x, 100x oil, incl. 208 camera (4K) ZAS5-0040
ZEISS Axioscope 5 LED/ HAL for transmitted light brightfield N-Achroplan 10x, 40x, 50x Oil, 100x Oil, incl. 208 camera (4K) for applications in microbiology ZAS05-0042
ZEISS Axioscope 5 LED/HAL for transmitted light brightfield N-Achroplan 10x, Plan-Apochromat 63x (oil), incl. 208 camera (4K) for haematology applications ZAS5-0043
ZEISS Axioscope 5 LED/HAL for transmitted light - brightfield N-Achroplan 2,5x, 5x, EC Plan-Neofluar 10x, 40x, incl. 208 camera (4K) for applications in cythology ZAS5-0044
ZEISS Axioscope 5 LED/HAL for transmitted light brightfield N-Achroplan 2,5x, EC Plan-Neofluar 5x, 10x, 20x, 40x, incl. 208 camera (4K) for applications in pathology and histology ZAS5-0046
ZEISS Axioscope 5 MAT, Filter AL HF/DF, LED for reflected light, brightfield and darkfield, Objectives EC Epiplan 5x, 10x, 20x, 50x, with phototube ZAS5MAT-0040
ZEISS Axioscope 5 LED fluorescence for RGB-UV combined with LED transmitted light, with objectives EC Plan-Neofluar 10x, 20x, 40x and with optional differential interference contrast, incl. 202 mono camera (4K) ZAS5-0051

Further Information

Product Details

Description

Smart microscope for biomedical routine and research

In the past, documenting samples with multiple fluorescent labels in your routine lab could be time consuming. You needed to manually switch filters, adjust illumination intensities and exposure times and to snap each single channel image. With Smart Microscopy from ZEISS, this is a thing of the past. Your Axioscope 5 with Axiocam 208 color or 202 mono and Colibri 3 LED illumination take this workload from you. All you have to do is focus and press Snap – and you’re done! You’ll work more efficiently, save time and produce high contrast images with best image quality.

Specifications:

Tripod equipment and accessories

Nosepiece 6x Coded
Filter wheel 6-fold for filters with diameter 36 mm in DL
Control button for Eco Mode and Light Manager
Snapshot function supports ZEISS Axiocam
USB 2.0 interface
Eyepieces 10x/23 Br. Foc
Camera adapter 60N-C 2/3" 0.5x

Overview of the possible variations:

	Methods	Objectives	Condensor	Illumination	Camera	Specials
ZAS05-0040	Brightfield	A-Plan oder N-Achroplan 5x,10x, 40x, 100x Oil	0,9/1,25 B	LED or HAL 50	Axiocam 208 color	-
ZAS05-0042	Brightfield optional Phase	N-Achroplan 10x,40x, 50xOil, 100x Oil	achromatic- aplanatic 0,9 B D Ph DIC	LED/(HAL 100)	Axiocam 208 color	For Microbiology, DIC / Ph-Optional, Ergonomic Kit
ZAS05-0043	Brightfield optional POL	N-Achroplan 10x,63x	achromatic- aplanatic 0,9 B	LED/(HAL 100)	Axiocam 208 color	For Hematoloy, more Objektivs and Filters
ZAS05-0044	Brightfield optional 40x Phase	N-Achroplan 2,5x, 5x, EC Plan-Neofluar 10x, 40x	achromatic- aplanatic 0,9 B	LED/(HAL 100)	Axiocam 208 color	For Zytology, Ergofototubus, optional Condensor Ph, 40x Ph Objektiv
ZAS05-0046	Brightfield optional POL	N-Achroplan 2,5x, EC Plan-Neofluar 5x, 10x, 20x, 40x	achromatic-aplanatic 0,9 B, Overview 2,5x/4x	LED/(HAL 100)	Axiocam 208 color	For Pathology/ Histology, optional Ergotubus, 63x Objektiv and Polarisation
ZAS05MAT-0040	Brightfield & Darkfield	EC Epiplan 5x, 10x, 20x, 50x	-	LED for reflected light	-	Material Science, Material testing, Quality assurance Filter AL HF/DF
ZAS05-0051	Brightfield/ Colibri 3-FL optional HXP120-FL	N-Achroplan or EC Plan-Neofluar 10x, 20x, 40x, 63x	0,9/1,25 B or achromatic-aplanatic 0,9 B D Ph DIC	LED/(HAL 100)	Axiocam 202 mono	Fluorescence GB-UV, optional DIC, Reflektorrevolver 4 or 6-times coded, optional div. FL-Filters
