ZEISS Axioscope 5/7 MAT - smart microscope for for research and routine in the materials laboratory

The popular microscope for research and routine in the materials laboratory

  • For materials research and metallography
  • Powerful with outstanding ease of use
  • Advanced light management
  • Digital instrument control up to digital archiving
  • Motorization of all axes of motion for automated imaging (Axioscope 7)



Grouped product items
Product Name Qty
ZEISS Axioscope 5 MAT, Filter AL HF/DF, LED for reflected light, brightfield and darkfield, Objectives EC Epiplan 5x, 10x, 20x, 50x, with phototube

ZAS5MAT-0040

ZEISS Axioscope 7 MAT MOT, filter AL HF/DF, LED for reflected light, brightfield and darkfield, motorized X-Y-Z axis, objectives EC Epiplan 5x, 10x, 20x, 50x, with photo tube

ZAS7MAT-0042

Product Details

Description

For demanding routine and advanced examinations

The Axiocsope product family has been optimized for use in specific application areas. You as the user are the focus and benefit from convenient operation and all relevant contrast methods for solving your microscopic tasks.

The Axioscope product family holds a well-defined place in the portfolio for materials analysis and metallography: Axioscope is the right choice if your routine tasks place high demands on user-friendliness, reproducibility and automation - and if, at the same time, you need scope for advanced materials science investigations that do not allow any compromises in analysis procedures and data quality.

As a complete materials laboratory solution, Axioscope is also the first choice from an economic point of view.





ZEN 2 core: Imaging software with material modules

ZEN 2 core is your command center for automated imaging and analysis functions. With modules for the determination of grain sizes, phase boundaries and layer thicknesses as well as for the classification of graphite particles, all essential metallographic applications are available under a uniform user interface.



Specifications:

Tripod equipment and accessories

  • Nosepiece 6x Coded
  • Filter wheel 6-fold for filters with diameter 36 mm in DL
  • Control button for Eco Mode and Light Manager
  • Snapshot function supports ZEISS Axiocam
  • USB 2.0 interface
  • Eyepieces 10x/23 Br. Foc
  • Camera adapter 60N-C 2/3" 0.5x

Overview of the possible variations:

  Methods

Objectives

Condensor

Illumination

Camera Specials
ZAS05MAT-0040 Brightfield & Darkfield EC Epiplan 5x, 10x, 20x, 50x  - LED for reflected light - Material Science, Material testing, Quality assurance
Filter AL HF/DF
ZAS7MAT-0042 Brightfield & Darkfield EC Epiplan 5x, 10x, 20x, 50x - LED for reflected light - Motorized X-Y-Z axis
Material Science, Material testing, Quality assurance
Filter AL HF/DF





More models and configurations available. For more information and support please contact us!


>>> Sales only within Germany! <<<

More Information

More Information
Type
AxioScope 5
