ZEISS Axiolab 5FL- LED Fluorescence Microscope

Revolutionizing Digital Documentation

  • Digital Fluorescence/Light Adjustment
  • Digital Objective Detection
  • Fast Image Acquisition on Microscope Tripod
  • 2 Megapixel CMOS Mono Camera
  • Multi-channel fluorescence images
Grouped product items
Product Name Qty
ZEISS Axiolab 5 for LED fluorescence in combination with brightfield with objectives N-Achroplan 5x, 10x, 40x and 100x with phototube, incl. Axiocam 202 mono

ZAL5-0003

ZEISS Axiolab 5 for LED fluorescence in combination with brightfield with objectives N-Achroplan 10x, 40x, 50x and EC Plan-Neofluar 100x with photo tube, incl. Axiocam 208 color, for Microbiology - with Fluorescence

ZAL5-0008

Product Details

Description

Your smart microscope for more efficient routine lab work

ZEISS Axiolab 5 FL-LED is ready for use without being dependent on a computer. In combination with the Axiocam 202 mono or Axiocam 208 color microscope cameras, you have all the advantages of an intelligent stand-alone microscope system: you can take images and videos directly on the tripod. Control the camera via the screen display using the mouse (and keyboard if necessary). Store all microscope and camera metadata, as well as scaling data.
The LED fluorescence is powerful, gentle on samples and extremely long-lasting. An adjustment of the fluorescent lamp is no longer necessary.



ZEISS ZEN for research applications

Use the ZEN Imaging Software from ZEISS to additionally process and analyse your images.







Specifications:

Tripod equipment and accessories

  • Nosepiece 6x Coded
  • Filter wheel 6-fold for filters with diameter 36 mm in DL
  • Control button for Eco Mode and Light Manager
  • Snapshot function supports ZEISS Axiocam
  • USB 2.0 interface
  • Eyepieces 10x/23 Br. Foc
  • Camera adapter 60N-C 2/3" 0.5x



Overview of the possible variations:

  Methods
Objectives
Condensor Illumination Camera Specials
ZAL5-0003

Brightfield/ Fluorescence

N-Achroplan 5x, 10x, 40x, 100xOil 0,9/1,25 B LED Axiocam 202
mono

Fluorescence-LED, Ex385nm, Ex470nm, Ex565nm
optional
HAL 35W

ZAL5-0008

Brightfield/ Fluorescence

N-Achroplan 10x,40x,50xOil, EC Plan-Neofluar 100xOil

achromatic-aplanatic 0,9 B D Ph DIC LED Axiocam 202 mono

For Microbiology, Fluorescence-LED, Ex 470nm,
optional
HAL 35W, further Objectivs



More models and configurations available. For more information and support please contact us!

>>> Sales only within Germany! <<<

More Information

More Information
Type
AxioLab 5
Application
LM
Fluorescence Microscopy
Manufacturer
ZEISS
