Triax™ Flow Cell (FC-3)
BFC-3
FC-3 is used for three wavelength scans, one or two for UV scans and the other one or two for the VIS scans. Up to three wavelengths can be recorded simultaneously in the same gradient. All three LEDs are driven and tuned simultaneously by using the Triax™ software.
Product Details
Description
Characteristics
- UV and VIS measuring cell
- Up to three wavelengths can be measured simultaneously
- Software updates via drop box
Technical Specifications
- Resolution: 1,040,000 units
- Automatically AUFS setting
- Flow cell: 2 x 2mm², 30µl
- UV-wavelength: 260nm, 280nm
- Fluorophores: EGFP, mCherry, AlexaFluor 488, AlexaFluor 555,
- AlexaFluor 568, Cy2, Cy3, Cy5 and more on request
- PC requirements: Win10, 2x USB-Port
Included
- Triax™ Flow Cell
- Triax™ Software
- Set of LED, Ex. filter, Em. filters
- USB cable PC to TriaxTM
- USB cable PC to Frac
- Connecting cables for fraction collector
- Assorted Cap & Set Screws
- IDEX Direct Injection Fitting w/20g needle
- IDEX Input Fitting & Ferrule
- 20 cm Alignment Extensions
- Flow Cell Cleaners
- Manual (English)
Technical Data
| Voltage | via USB (CE certified) |
| Dimensions | 139,0mm x 62,0mm x 89,0mm (W/D/H) |
| Weight | 5,9kg |
