TEM Grids, Carbon Film coated, 200 Mesh, Gilder Finder F2, Cu
A thin film of pure carbon deposited on one side of the grid. Mechanically not as stable as formvar films, but show better electrical and heat conduction in the electron beam. The thickness range is as follows:
- Standard: Approx. 5-6nm
- Ultra-Thin (UL): 3-4nm
- Thick (TH): 10nm
- Extra Thick (ET): 20-30nm
Product Details
Description
All of our film is laid on the shiny side of the grid.
More Information
| Coating |
Carbon
|
|---|---|
| Type |
Finder Grids
|
| Grid Size | 3,05mm |
| Material |
Copper
|
| Material Symbol | Cu |
| Mesh Size |
200 Mesh
|
| Mesh Style |
Finder
|
| Manufacturer |
EMS
|
