Silver Conductive Adhesive 478SS Paste und Thinner

Silver Conductive Adhesive 478SS is a conductive, silver-based polymer which is used for thick film coatings where liquid silver is not recommended. It offers a very high Tg (glass transition temperature) of 67°C to prevent blocking and offers superior adhesion to polyester film. Adhesive 478SS can be cured at 93°C within 15 minutes.

Grouped product items
Product Name	Qty
Silver Conductive Adhesive 478SS, Thinner, 25ml E12685-25 €19.10 €22.73

Product Details

Description

The Silver Conductive Adhesive 478SS is a conductive, silver-based polymer. It is a thick film ink that is used to conduct screen printing onto membrane switches. It can be heat cured for maximum performance. In addition, it is compatible with surface mount epoxy systems, has an extended screen residence time, has a high glass transition temp. (Tg) to prevent any blocking, has outstanding creasability, excellent adhesion to polyester film, and has a very low sheet resistance, Furthermore, it has superior abrasion resistance and hardness.

Key properties

Ready to use
Apply by standard screen printing process
Cures at 93°C in 15 minutes
Very high Tg (glass transition temperature) at 67°C to prevent any blocking
Compatible with epoxy systems
Outstanding creasability
Excellent adhesion to polyester films
Very low sheet resistance
Superior abrasion resistance and hardness

Specifications

Solid components	Silver 73%
Sheet Resistance	0.02 - 0.05 ohms/sq/mil
Density	2,52 kg/l
Shelf life	1 year at -12 to 27°C
Dilute	5%/weight carbitol acetate, E12685-25 Silver Conductive Adhesive 478SS Thinner

More Information

More Information
Symbol GHS	GHS05 GHS07
Signal word	Danger
Mandatory sign	Tightly sealed goggles Protective gloves
Hazard statements	H225 H319 H335
Precautionary statements	P210 P241 P303_361_353 P305_351_338 P405 P501
Storage Temperature	RT
Shipping Class	Hazardous Good LQ
SDS (multilingual)	E12685-15, E12685-25
