OPTIKA, B-510 advanced routine microscope
Product Details
Description
This series offers a user-friendly and robust microscope with good quality optics for advanced routine microscopy in biology, histology or cytology. The IOS W-PLAN objectives ensure field flatness up to F.N. 22 and provide good contrast and resolution suitable for easy research applications.
The Full Koehler system combined with the X-LED3 lighting source ensures homogeneous illumination of the specimen with reduced image artifacts.
The optional multi-head observation system is ideal for teaching or training students, especially in the medical field. Up to five users can simultaneously observe and discuss the same image. Objects and points of interest can be highlighted by a three color LED pointer.
This series is available with brightfield, darkfield, phase contrast, polarisation, fluorescence and incident light.
Model* | Head | Objectives | Condensor | Attachment |
OPB-510BF | Trinocular (50/50) |
IOS W-PLAN 4x, 10x, 40x, 100x (oil) |
0.2/0.9 N.A swing out condenser | |
OPB-510PH | Trinocular (50/50) | IOS W-PLAN 10xPH, 20xPH, 40xPH, 100xPH (oil) |
phase condenser with 10x – 100x, BF, DF | - |
OPB-510MET | Trinocular (50/50) | IOS N-PLAN 4x, 10x, 20x, 40x, 100x (oil/water) |
- | 8W X-LED8 with white LED incident light |
OPB-510LD1 | Trinocular (100/0, 50/50, 0/100) | 0.2/0.9 N.A swing out condenser |
High power blue LED fluorescence with 3-position filterset slider, blue filterset (FITC) included |
*other configurations on request
More Information
Eyepieces | WF 10x/22 High eye-point |
---|---|
Type |
B-380 series
|
Condensor | Abbe N.A. 1.25, iris diaphragm, focusable and centrable |
Application |
LM
Fluorescence Microscopy
|
Head | Trinocular (50/50), 30° inclined, 360° rotating |
Illumination | 3.6 W X-LED3, brightness control, full-koehler |
Stage | 233x147mm, moving range 78x54 mm |
Packing Unit | each |
Nosepiece | Quintuple, reversed |
Manufacturer |
OPTIKA
|
