OPTIKA B-510LD4 Trinocular LED fluorescence microscope, IOS W-PLAN objectives

OPB-510LD4

Advanced routine fluorescence microscope for transmitted brightfield and fluorescence observations with IOS W-PLAN objectives. The extremely powerful LED Fluorescence Illuminators are combined with corresponding excitation filter sets for the visualization of most fluorochromes. LED fluorescence ensures unparalleled convenience eliminating warm-up/cool-down times and all the inconveniences related lamp replacement and adjustment. Transmitted light through the exclusive X-LED3 to ensure great-looking, rich and high-quality specimen view.

€2,472.00 €2,941.68

Product Details

Description

This fluorescence microscope offers a user-friendly and robust microscope with good quality optics for advanced routine microscopy in biology, histology or cytology. The IOS W-PLAN objectives ensure field flatness up to F.N. 22 and provide good contrast and resolution suitable for brightfield and fluorescence microscopy.
The Full Koehler system combined with the X-LED³ lighting source ensures homogeneous illumination of the specimen with reduced image artifacts.

The LED fluorescence ensures a long lifespan and is free from warm-up and cooldown times.

Standard filterset

Name: Blue (FITC)
Excitation filter: 460-490nm
Dichroic mirror cut-off: 505nm
Emission filter: 515LP

More Information

More Information
Condensor	Swing-out N.A. 0.2/0.9, with iris diaphragm, focusable and centerable
Eyepieces	WF 10x/22, high eye-point and with rubber cups
Head	Trinocular (100/0, 50/50, 0/100), 30° inclined, 360° rotating
Illumination	Transmitted illumination: 3.6W X-LED3 Full-Koehler / Fluorescence: High-power blue LED, 4-position filter holder, none included
Nosepiece	Quintuple reversed
Objective	IOS W-PLAN 4x/0.10 10x/0.25 40x/0.65 100x/1.25 (oil)
Packing Unit	each
Stage	233x147mm, moving range 78x54 mm
Manufacturer	OPTIKA
