OPTIKA, B-1000 modular research lab upright microscope

The high modularity of the B-1000 series offers multiple configuration options that can be individually adapted to the customer's needs to ensure accurate and efficient diagnostics. Modularity ranges from manual operation to the motorized version with a wide selection of objectives, stages and condensers. The quality optics (Semi-Apo lenses) and the X-LED8 (8W) illumination system make it suitable for routine and research applications.

Grouped product items
Product Name Qty
OPTIKA, B-1000FL-LED fluorescence research lab microscope, LED fluorescence with

OPB-1000FL-LED

OPTIKA, B-1000BF research lab microscope, brightfield

OPB-1000BF

OPTIKA, B-1000PH research lab microscope, phase contrast

OPB-1000PH

Product Details

Description

The B-1000 series offers full modularity from manual control to motorized options, including motorized nosepiece, stage and focus. The X-LED8 (8W) illumination system corresponds to 100W halogen bulb and is expandable with the Automatic Light Control (ALC). The ALC regulates the light intensity to a constant brightness no matter if the objective or the aperture of the diaphragm is changed. The microscope adjusts the light intensity to the preferred brightness by pushing a button.
The Full Koehler system combined with the X-LED8 lighting source ensures homogeneous illumination of the specimen with reduced image artifacts.

The selection of optics ranges from N-Plan to Semi-Apochromatic objectives and gives large overview with a field of view of 24mm.

The Microscope is available with brightfield, phase contrast and fluorescence with HBO or LED for use in biology, histology, cytology and pathology.



Model*

Head

Objectives

Condenser

Fluorescence

OPB-1000BF

Trinocular ERGO (100/0, 50/50)

IOS U-PLAN F

4x, 10x, 20x, 40x,

100x (oil)

0.9 N.A swing out condenser

-

OPB-1000PH

Binocular ERGO

IOS W-PLAN

10xPH, 20xPH, 40xPH,

100xPH (oil)

1.25 N.A. phase contrast condenser with 10x – 100x, BF, DF

-

OPB-1000FL-HBO

Trinocular ERGO (100/0, 50/50, 0/100)

IOS U-PLAN F

4x, 10x, 20x, 40x,

100x (oil)

1.2 N.A. swing out condenser

6-position HBO Fluorescence attachment, with Blue & Green filtersets

Optional:

V filter set

UV filter set

*more configurations on request

More Information

More Information
Eyepieces PL 10x/22 / PL 10x/24
Condensor Abbe N.A. 1.25, iris diaphragm, focusable and centrable
Application
LM
Fluorescence Microscopy
Head Binocular ERGO / Trinocular (100/0, 50/50, 0/100)
Illumination 8 W X-LED8 / Full-Koehler / Optional ALC
Stage Standard mechanical stage. Heating stage with digital temperature controller. Motorized mechanical stage
Packing Unit each
Nosepiece Sextuple reversed with DIC slot / Sextuple motorized reversed with DIC slot
Manufacturer
OPTIKA
