NIGHTSEA™ Fluoreszenz-Adapter für Dino-Lite Digitalmikroskope, verschiedene Filtersätze

NIGHTSEA™ Fluorescence Adapter for Dino-Lite Digital Microscopes, various Filter Sets

The NIGHTSEA™ Fluorescence Adapter enables fluorescence imaging with the Dino-Lite® digital microscope series.

The modular design allows easy switching between excitation/emission wavelengths. The broad excitation spectrum gives a wide range of applications from biology to geology and material research.

For large working distances, the Nightsea adapter is also recommended for Dino-Lite fluorescence models to optimize fluorescence excitation.

Grouped product items
Product Name	Qty
NIGHTSEA™ Fluorescence Adapter for Dino-Lite, Filter Set UV ESFA-DL-UV €2,187.20 €2,602.77
NIGHTSEA™ Fluorescence Adapter for Dino-Lite, Filter Set Violet ESFA-DL-VI €1,952.00 €2,322.88
NIGHTSEA™ Fluorescence Adapter for Dino-Lite, Filter Set Royal Blue ESFA-DL-RB €1,952.00 €2,322.88
NIGHTSEA™ Fluorescence Adapter for Dino-Lite, Filter Set Royal Blue with bandpass filter (green only) ESFA-DL-RB-GO €1,952.00 €2,322.88
NIGHTSEA™ Fluorescence Adapter for Dino-Lite, Filter Set Cyan ESFA-DL-CY €1,952.00 €2,322.88
NIGHTSEA™ Fluorescence Adapter for Dino-Lite, Filter Set Green ESFA-DL-GR €1,952.00 €2,322.88

Product Details

Description

Compatible Dino-Lite models
The NIGHTSEA fluorescence solution is best suited for Dino-Lite models with a long working distance (LWD). High magnification Dino-Lite models have a very short working distance, meaning that good illumination of the sample cannot be guaranteed.

Compatible with the following Dino-Lite white light models:

AF4915ZTL
AM7115MZTL
AM7915MZTL
AM73915MZTL

The higher power of the NIGHTSEA system LEDs can supportively enhance performance of some Dino-Lite fluorescence models. Especially at longer working distances, when the intensity of the built-in Dino-Lite LEDs is not sufficient to provide fluorescence excitation of the sample.

And with the following fluorescent models:

AM4117MT-G2FBW
AF4115T-GRFBY
AM4117MT-CFVW
AF4515TL-FVW
AF4515T-FVW

Dino-Lite AM4115T-CFVW, image made with Dino-Lite excitation (left), NIGHTSEA excitation (right)

Dino-Lite AM4115T-GRFBY, image made with Dino-Lite excitation (left), NIGHTSEA excitation (right)

The NIGHTSEA™ fluorescence adapter for the Dino-Lite® digital microscope series is an easy alternative to add fluorescence to Dino-Lite microscopes. NIGHTSEA™ uses the latest LED technology and is available for different excitation/emission wavelengths. With a simple click system, filter sets can be changed in seconds.

NIGHTSEA™ is available for the following wavelengths:

Filter Set	Color	Excitation	Emission Filter
UV	Ultra violet	360 - 380nm	415nm Long pass
VI	Violet	400 - 415nm	450nm Long pass
RB	Royal Blue	440 - 460nm	500nm Long pass
RB-GO	Royal Blue	440 - 460nm	500-560nm Band pass
CY	Cyan	490 - 515nm	550nm Long pass
GR	Green	510 - 540nm	600nm Long pass

The wavelength sets are named, and color coded according to the color of the excitation light, not according to the color of the emitted fluorescence. The color coding ensures the use of the correct filter/LED head combination.

The NIGHTSEA™ Fluorescence Adapter for Dino-Lite consists of:

Flexible gooseneck lamp holder incl. power supply
LED light head for excitation, available in different wavelengths
Ring-shaped emission filter - easy to attach
Emission filter googles

Sample images made with various Dino-Lite/NIGHTSEA adapter combination:


Fluorescent markings in currency. UV excitation	Fluorescence in a cicada. Violet excitation	Fluorescence from chlorophyll in a leaf. Royal Blue excitation


Gel defect in nylon granules. Royal Blue excitation	Fluorescent mineral with calcite (red) and willemite (green). Royal Blue excitation
