NIGHTSEA™ Add-On Light and Filter Set, V1 Connector
Product Details
Description
NIGHTSEA™ Add-On Licht-Kopf und Filterset für das NIGHTSEA™ Stereomikroskop Fluoreszenz-Adapter ist für mehrere Anregungs-/Emissions-Wellenlängen erhältlich. LED-Kopf und Filter können in Sekundenschnelle ausgetauscht werden. Eine Farb-Kodierung gewährleistet die Verwendung der korrekten Filter/LED-Kopf Kombination.
|
Artikelnr. |
Filter Set | Anregung | Emission | Fluorophor |
| ESFA-LFS-RB | RB- Royal Blau | 440-460 nm | 500 nm LP | EGFP, Fluorescin, Alexa488. ... |
| ESFA-LFS-CY | CY - Cyan | 490-515 nm | 550 nm LP | YFP, Venus, Lucifer Yellow, ... |
| ESFA-LFS-GR | GR - Grün | 510-540 nm | 600 nm LP | DsRed, dTomato, Alexa568... |
| ESFA-LFS-VI | VI - Violett | 400-415 nm | 460 nm LP | CFP, ... |
| ESFA-LFS-UV | UV - Ultra Violett | 360-380 nm | 415 nm LP | DAPI, ... |
Achtung: Es gibt zwei verschiedene Steckertypen für LED-Kopf. Beide Typen sind nicht miteinander kompatibel. Der neue Stecker ist ein BNC Stecker, der ältere wird als V1 bezeichnet. Die Stecker sind sehr leicht von einander zu unterscheiden:
- Der BNC Stecker an der Schwanenhals Lampenhalterung ist silber (V1 ist schwarz).
- Die LED-Köpfe mit einem BNC Stecker sind mit einer Markierung "BNC" an der Seite versehen..
More Information
| Type |
Illumination
|
|---|---|
| Packing Unit | Set |
| Used with |
Stereo Microscopes
|
| Manufacturer |
NIGHTSEA
|
-
Starting at €1,920.90 €2,285.87
NIGHTSEA™'s new Stereo Microscope Fluorescence Adapter adds fluorescence to just about any stereo microscope (or dissecting microscope) with no modification to the microscope itself. The modular design lets you easily switch between several excitation / emission combinations to work with a variety of fluorescent proteins and other fluorophores.
The NIGHTSEA™ comes now with a BNC-connector.
Starting at €1,920.90 €2,285.87
-
€447.20 €532.17Art.Nr: ESFA-LH-WHA LED white light head is also available as an illumination option for the Stereo Microscope Fluorescence Adapter. Now if you are using the NIGHTSEA™ system for fluorescence you do not need a separate light source for your white-light work - just exchange the fluorescence excitation light head module for the white-light module in a matter of seconds. Extremely convenient for general illumination and as a focusing aid for fluorescence imaging. Comes with a BNC connector.€447.20 €532.17 -
Starting at
The NIGHTSEA™ light-head hangers and cables conveniently hold the light-head instead of the gooseneck lamp. The hangers mount to the thumbscrews on the SFA adapter ring. They are available with two different pivot arm lengths for use with long and short working distance microscopes.Starting at
