L2, Slit Aperture for electron microscopes, 2x1000µm

PY04D00950

Material: Cu, Rectangular Slit: 2x1000µm, Dimensions: 16mm / 3mm (Foil), Thickness: 0,025mm
€292.24 €347.77

Product Details

Description


Mounted Slits - L Serie

Spectrophotometer entrance and exit slits. Imaging and alignment applications suitable for complete UV - IR frequency range.

Manufactured by a process that produces ultra high edge definition, shape and size. The metal profile is such that the minimun dimension of the aperture is within a micron of one face.

Aperture sizes are measured at up to 1000x magnification and the tolerance below apply to the width throughout the length.

Each slit is centered in a copper foil disc, 15-25 microns thick, mounted in a recessed hole in an anodised aluminium holder.


Range               Tolerance

1-25µm             +/-0,5µm


More Information

More Information
Type
Slit Apertures
Dimensions 16mm / 3mm (Foil)
Foil Thickness 15-25µm
Material
Cu
Packing Unit each
Manufacturer
Graticules Optics
