Gold on Carbon Test Standard, ultra high resolution

With gold particles ranging from <2nm to 30nm, this test is suitable for ultra high resolution SEM tests such as field emission electron source. A magnification of at least 80,000x is required for this test.

Grouped product items
Product Name	Qty
Gold on Carbon Test Standard, Ultra High resolution, ISI Stub P79512-03 €309.40 €368.19
Gold on Carbon Test Standard, Ultra High resolution, Hitachi Stub P79512-04 €369.20 €439.35
Gold on Carbon Test Standard, Ultra High resolution, Carbon Planchet 1,6mm, each E79512-05 €834.90 €993.53
Gold on Carbon Test Standard, Ultra High resolution, JEOL Stub P79512-02 €309.40 €368.19

Product Details

Description

SEM resolution is tested in terms of a combination of criteria, namely resolved gaps and the number of gray levels in the image. This is to ensure that the resolution has not been distorted by using the contrast to maximize visibility of edges. High resolution images ideally should show fine detail together with a lack of noise evidenced by a good range of gray levels.
