Disc Aperture for Phillips, Cameca electron microscopes, D 100µm

E40100-Pt

Material: Pt, Aperture Diameter: 100µm, Dimensions: 2mm, Thickness: 0,24mm
€149.10 €177.43

Product Details

Description

Platinum Disc, Drilled Apertures

Platinum apertures are easily cleaned by either an aperture flamer or over a bunsen burner in the open air. We maintain a wide variety of Platinum Drilled Apertures in stock with different configurations suiting all of your needs.

Platinum Apertures size tolerances vary as follow:

  • Nominal hole diameter +/- 1 micron
  • Disc diameter +/- 10microns
  • Disc thickness +/- 10microns

More Information

More Information
Type
Disc Apertures
Aperture Diameter
50-100µm
Dimensions 2mm
Material
Pt
Packing Unit each
