Dino-Lite Edge 5MP AM7115MZT, each
DLAM7115MZT
The all-in-one Dino-Lite Edge 5MP AM7115MZT digital microscope has a wide magnification range from 20x to 220x, 5MP image sensor and cutting-edge optics. The crisp image quality, the built-in polarizer, interchangeable front caps and the robust metal housing making it a very versatile Dino-Lite device for a wide range of applications.
Features: 5 MP, AMR, FLC, POL
Product Details
Description
High optical resolution
The superior optics adopted in the Edge series reveals the finest details, answering the needs of the most demanding microscopy applications.
5.0 Megapixels
The low loss MJPEG compression and the advanced CMOS image sensor allows to transmit fluid and crisp image with resolution up to 2592x1944.
Flexible LED Control (FLC)
The FLC maximizes illumination flexibility by offering independent on/off control of the four LED quadrants in addition to the 6 intensity level adjustment.
Adjustable polarizer
The built-in adjustable polarizer allows to remove freely the unwanted reflections or glare from the object surface for a better contrast.
Scroll Lock
The scroll lock ensures the focus knob staying at the desired focus or magnification position without worry of unintentional movement.
Robust housing
The metal housing made of aluminium alloy offers compelling advantages of protection and endurance.
Interchangeable caps
Interchangeable caps provide adaptability to numerous applications with alternative lighting or object interface, such as but not limited to diffused-light, ringlight, and coaxial-light etc.
| Model | AM7115MZT Dino-Lite Edge |
| Interface | USB 2.0 |
| Product Resolution | 5M pixels (2592x1944) |
| Magnification | 20x~220x |
| Frame Rate | 10fps in 5MP/3MP/2MP, MJPEG 25fps in 1.3MP, MJPEG 30fps in 640x480 (VGA), MJPEG |
| Saving Format |
Image: Video: |
| Lighting | 8 white LEDs |
| Polarizer | Yes |
| Microtouch | Yes |
| Operating System Supported | Windows XP/7/8/10/11 macOS 10.14 or later |
| System Requirements | ‧ Intel Core2 Duo @ 2.20 GHz/AMD Athlon X2 Dual Core BE-2400 (2.3GHz) ‧ 20GB available HD space ‧ 2GB available RAM or more ‧ 512MB video card or more ‧ CD-ROM drive for installation ‧ USB 2.0 |
| Calibration Function | Yes |
|
Measurement Function |
Yes |
| Unit Dimension | 10.5cm (H) x 3.2cm (D) |
| Unit Weight | 135g |
More Information
| Packing Unit | each |
|---|---|
| Manufacturer |
Dino-Lite
|
-
