Dino-Lite Edge 1.3MP Fluorescence 480nm/510nm AM4115T-GFBW, each
DLAM4115T-GFBW
The Dino-Lite Edge AM4115T-GFBW has a 1.3 MP CMOS sensor and allows magnifications from 20x to 220x. This digital microscope is optimized for acquisition of fluorescent objects using blue 480nm LEDs for excitation and a 510nm emission filter for visualization of green fluorescence (GFP, Alexa 488, etc.) in biology or material research. The built-in white-light LED enables focussing and locating the desired object.
Features: 1.3 MP, Fluorescence
Product Details
Description
Bildlaufsperre
Die Bildlaufsperre arretiert den Vergrößerungs-/Fokusknopf in der gewünschten Position, um ein unbeabsichtigtes Verstellen zu verhindern.
Fluoreszenz 480nm/510nm
Integrierte blaue 480nm LEDs zur Anregung mit einem 510nm Emissionsfilter. Eine weiße LED zur Lokalisierung und Fokussierung von Regionen von Interesse ist zudem enthalten.
Hohe Empfindlichkeit für grüne Fluoreszenz
Ein hochempfindlicher 1.3-Megapixel-Sensor kombiniert mit einem speziell entwickelten Objektiv zur Erfassung schwacher Fluoreszenzsignale machen es mit einigen traditionellen Mikroskopen vergleichbar.
Flexible Vergrößerung
Drehrad zur Einstellung der Vergrößerung in einem Bereich von 20x - 220x je nach Arbeitsabstand
USB 2.0-Schnittstelle
Für die Stromversorgung des Geräts ist lediglich ein USB 2.0-Anschluss erforderlich. Zur Analyse und Dokumentation kann es über die bereitgestellte Software mit einem kompatiblen PC/MAC verbunden werden.
| Model | AM4115T-GFBW Dino-Lite Edge |
| Interface | USB 2.0 |
| Product Resolution | 1.3M pixels (SXGA) |
| Magnification | 20x~220x |
| Sensor | Color CMOS |
| Frame Rate |
Up to 30fps |
| Save Formats |
Image: Movie: |
| Microtouch | Touch sensitive trigger on the microscope for taking pictures |
| Lighting | Using 7 blue LEDs for excitation lighting and has a 510nm emission filter/1 white LED switched by software |
| Operating System Supported | Windows XP/7/8/10/11 macOS 10.14 or later |
| System Requirements | ‧ Intel Core2 Duo @ 2.20 GHz/AMD Athlon X2 Dual Core BE-2400 (2.3GHz) ‧ 20GB available HD space ‧ 2GB available RAM or more ‧ 512MB video card or more ‧ CD-ROM drive for installation ‧ USB 2.0 |
| Calibration Function | Yes |
|
Measurement Function |
Yes |
| Unit Dimension | 10.5cm (H) x 3.2cm (D) |
| Unit Weight | 100g |
