Dino-Lite Edge 1.3MP AF4915ZTL, each
DLAF4915ZTL
The Dino-Lite Edge 1.3MP AF4915ZTL is an all-in-one device with long-working-distance (LWD) and adaptable interface. It is designed for (professional) applications within 10-140x magnification. The crisp image quality making it a very versatile Dino-Lite device. Transform the AF4915ZTL from USB2.0 connection to a wireless microscope for field applications with the Wi-Fi streamer WF-20 (optional).
Features: 1.3 MP, LWD, EDOF, EDR, AMR, FLC, POL (EDOF/EDR on Windows PC only)
Product Details
Description
High optical resolution
The superior optics adopted in the Edge series reveal fine details for most demanding microscopy applications.
1.3 Megapixels
The low loss MJPEG compression and the advanced CMOS image sensor allow to transmit fluid and crisp images with resolution up to 1280x1024.
Adaptable interface
The adaptable interface provides the capability of transforming Dino-Lite into a wireless microscope when attaching with WF-20 WiFi-Streamer (optional).
Flexible LED Control (FLC)
The FLC maximizes illumination flexibility by offering independent on/off control of the four LED quadrants in addition to the 6 intensity level adjustment.
Long-Working-Distance (LWD) optics
The LWD optics yields more working space between the object and the microscope, making it ideal for applications such as repairing or assembly.
Extend Depth of Field (EDOF)
Viewing rough surface with height range out of depth of focus, the EDOF can take several images at different focus and stack them automatically within a click.
Extend Dynamic Range (EDR)
Observing high contrast or reflective surfaces, the EDR can help to reveal the details of dark or bright areas by stacking images taken at different exposure levels.
Automatic Magnification Reading (AMR)
Without stopping and checking the magnification for measurements, the AMR detects the magnification rate automatically, for more efficient, accurate, and pleasant measurements.
Adjustable polarizer
The built-in adjustable polarizer allows to remove freely the unwanted reflections or glare from the object surface for a better contrast.
Scroll Lock
The scroll lock ensures the focus knob staying at the desired focus or magnification position without worry of unintentional movement.
Robust housing
The metal housing made of aluminium alloy offers compelling advantages of protection and endurance.
Interchangeable caps
Interchangeable caps provide adaptability to numerous applications with alternative lighting or object interface, such as but not limited to diffused-light, ringlight, and coaxial-light etc.
| Model | AF4915ZTL Dino-Lite Edge |
| Interface | USB 2.0 |
| Product Resolution | 1.3M pixels (1280x1024) |
| Magnification | 10x~140x |
| Frame Rate | 15fps in 1.3MP, MJPEG 30fps in 640x480 (VGA), MJPEG |
| Saving Format |
Image: Video: |
| Lighting | 8 white LEDs |
| Polarizer | Yes |
| Microtouch | Yes |
| Operating System Supported | Windows XP/7/8/10/11 macOS 10.14 or later (EDOF/EDR are NOT controllable on macOS) |
| System Requirements | ‧ Intel Core2 Duo @ 2.20 GHz/AMD Athlon X2 Dual Core BE-2400 (2.3GHz) ‧ 20GB available HD space ‧ 2GB available RAM or more ‧ 512MB video card or more ‧ CD-ROM drive for installation ‧ USB 2.0 |
| Calibration Function | Yes |
|
Measurement Function |
Yes |
| Unit Dimension | 11.4cm (H) x 3.3cm (D) |
| Unit Weight | 111g |
More Information
| Packing Unit | each |
|---|---|
| Manufacturer |
Dino-Lite
|
-
