Conductive Silver Epoxy Kit, fast curing, 2x 7g

Conductive Silver Epoxy Kit is a fast setting silver filled epoxy and ideal when time is the limiting factor. Gives a 10 minutes working window and cures in 15min at the relatively low curing temperature of 65°C. Conductive and mechanical properties will be sufficient for most for non-critical applications. The EM-Tec AG31 represents the most economical silver filled epoxy. It should not be used for applications where shrinkage is a limiting factor. Easy mixing ratio of 1:1 by volume.

To improve conductivity and to make mixing easy, both components are silver loaded. The amounts of the silver epoxy sets are chosen for affordability, yet sufficient for experiments, sample preparation and prototyping.

Key properties

• Fast setting
• Curing in 15min at 65°C
• Comes in two syringes, mix 1:1
• Do not use when shrinking is a limiting factor
• Do not thin

Specifications
